Feeder

Single nozzle electronic feeder

Power

Electromagnet brake pan;

Motor: 1.1 kw for 135cm 150cm, 1.5kw for 190cm

Weft insertion

Single steel tube nozzle, pipe-shaped reed

Shedding

Crank opening with two pieces heald frame.

Let-off

Passive or mechanical

Take-up

Inside or outside machine body

Beating

Four shedding lever winding beating

Selvage

Close and rough selvage

Running speed

400~500rpm

Weight

1.3~1.8t

Dimensions

135cm machine: 3050mm*1540mm

150cm machine: 3200mm*1540mm

190cm machine: 3600mm*1540mm

Device width 1300mm for outside take-up
